Cosmetics

The brushes are led from a hopper system into a feeding bowl where the parts are separated and sorted in hanging position on the accumulation line. After the accumulation line, a gripper transfers two parts at a time to the customer’s system.

Performance: 50 pcs/min

Operation Description: The Razors are fed by a hopper to a bowl feeder for orientation all one way and passed onto a vibratory linear feeder for accumulation storage. A camera station inspects the razor blade cover for rotational accuracy on the linear feeder tracking. Out of tolerance components are blown off the linear track via an air blast from the camera reject signal. A cute with reject confirmation sensor deposits the bad components into receptacle. Components within customers set tolerance are fed onto a further linear feeder to a waiting station for the pick & place unit. A specially designed vacuum gripper picks five parts at a time and places them into the packaging machine conveyor slats.

Performance: 30 second cycle giving a bowl feeding speed of 150 parts per minute

Inside the feeding bowl, the parts are sorted on two tracks and led to two accumulation lines. At the take-off station, suction devices place the plastic sheathings onto a 12-piece loading plate. This loading plate is then turned by 90° to the required layer of parts and all parts are transferred by a suction system to the customer’s system.

Performance: 18 pcs/min

Operation Description: The nail polish brushes are fed via the customer’s existing assembly machine hanging one behind the other into the linear track. The linear track is inclined for the first half which enables the bristles to be dipped into a lacquer bath. They are then led out of the lacquer bath again through the ascending linear track and transferred to the subsequent drying tower. The 11 minutes for component drying time is achieved via a guide track of about 52 metres in length.

Performance: 300 parts per minute
