FlexType™ P Pack
A STANDARD FLEXIBLE PACKING SOLUTION
RNA’s FlexType™ P Pack presents a flexible automatic packing solution that utilizes intelligent vibration platforms combined with industrial machine vision recognition and a 6-axis robot to feed and pack component parts of various shapes and sizes.
Downloads
FlexType™ P Pack
Offers flexibility, quick delivery time, reusability and speed.Included in FlexType™ P Pack Flexible Packing Machine
1. RNA Bulk Hopper
1/5
RNA Bulk Hopper
Standard off the shelf or custom bulk storage solutions; Various hopper size
Contact us
2. Flexible Feeder
3. Vision System
4. 6-Axis Robot with Custom Gripper
5. Bagging Machine
1/5
RNA Bulk Hopper
Standard off the shelf or custom bulk storage solutions; Various hopper size
Contact us
Links:
2/5
Flexible Feeder
FlexCube™ 50/80/250/380/530
FlexiBowl® 200/350/500/650/800/1200
Other flexible feeders to suit your application
Contact us
FlexiBowl® 200/350/500/650/800/1200
Other flexible feeders to suit your application
Links:
4/5
6-Axis Robot with Custom Gripper
A suitable 6-axis robot depending on payload and reach for handling and manipulating the products
Contact us
5/5
Bagging Machine
Compatible with customer preferred bagger, with customising options to suit the application
Contact us
6 STEPS
FlexType™ P Pack | RNA FLEXIBLE PACKING MACHINE
FLEXIBLE, RELIABLE AND STANDARD SOLUTION FOR THE AUTOMATED HANDLING AND PACKING IN 5 STEPS
STEP 1: Various parts to be bagged are loaded in bulk into hoppers. Parts drop by vibration from hoppers onto flexible feeder platforms on demand.
STEP 2: The flexible feeder complete pre-programmed vibratory cycles to orientate and separate component parts, presenting them to an integrated vision system for robot pick.
STEP 3: The vision system inspects the component parts on the flexible feeder platforms and identifies which are laying in a position suitable for being picked. The coordinates are sent to the robot.
STEP 4: A 6-Axis Robot, with suitable end of arm tooling picks all identified component parts and transfer them to the bagging machine.
STEP 5: Component parts are loaded to the bagging machine via a chute. The bagging machine presents a single opened bag per cycle, before sealing and dropping the bagged parts into a rotating chute which diverts bags into the designated storage box.
Key Benefits
Flexible feeding
- An alternative to traditional vibratory bowl feeders
- Experience seamless, software-based part changeovers in minutes
- Easily process a wide range of part sizes and shapes
- Handle multiple variants or parts with complex geometries
Flexibility for part changeover
- Interchangeable FlexCube™ platform for part pre-orientation
- Teachable vision system with auto-calibration of vibration parameters
Easy handling of variants
- Variants are stored by the controller
- Only 2 minutes needed to bring a new variant into production
Short delivery time
- Fully standard
- Pre-designed
Flexible packing solution
- Can accommodate multiple variants
- Robotic part transfer
- Multiple bagging machine options
High reusability
- Over 95% reusability, reducing investment
- Minimal specific tooling required
Fast implementation
- Standard platform design
- Standalone package with integrated controls
Easy configuration and installation
- Quick setup and reprogramming for new applications
- Rapid adjustment to changing production needs
Watch
FlexType™ P Pack Flexible Packing Machine, coupled with intelligent vibration platforms, industrial machine vision recognition and 6-axis robot
Also available in:
English
HOPPER
FLEXIBLE FEEDER
- Compatible with all parts geometries
- Minimum change-over times
- Extremely gentle part handling
- Free movement of parts
- No transmission of vibrations to the rest of the line
- Systematic part orientation
- Easy configuration with the feeding software
HOPPER
HOPPER SYSTEMS
- Compatibility: RNA BVL-P hopper systems are designed to fit various platform sizes and feeding tasks.
- Plug and play: Our hopper systems come factory-tuned and are easily integrated into the complete setup thanks to the enclosed control system. The discharge height is optimized for part transfer to the downstream FlexCube™ system.
- Demand-based feeding: BVL-P hopper systems ensure optimized part transfer rates to the sorting platform—crucial for achieving short sorting cycle times.
- Enhanced autonomy: The filling volume can be easily adjusted to your needs by adding static or upstream hopper units. Communication between these hopper systems is managed via RNA controllers.
HOPPER
VISION | SMART CONTROL SYSTEM
- Easy to use
- Intuitive recipe creation and configuration
- Plug and play
- Highly competitive system costs
- Compatible with any PLC & industrial robot brand
ROBOT & NEST
6-AXIS ROBOT & PACKING MACHINE
- Fully integrated: Compatible with the customer’s preferred 6-axis robot, featuring a custom gripper system tailored to the application — with quick-change capability if required.
- Quick change: Minimize downtime with seamless changeover of both the robot gripper system and assembly fixture nest.
- Customized: Application-specific gripper system and fixture nest.
- Automatic bagger: Compatible with the customer’s preferred bagging machine, with customization options to suit the application.
