Hoppers & Elevators

• Fill volumn up to 200 Litres
• Fill weight up to 200 kg
• Product features – see BVL model
• More robust design; made for higher filling
  weights

• All hoppers (BVL3, BVL5, BVL15, BVL50, BVL70, BVL100) are available in 3 to 100 litres
• Fill weight up to 50 kg
• Stainless steel hopper, integrated with RNAstandard equipment and control boxes
• Component parts are separated in advance towards the outlet with increasing speed
• Available from stock
• Off the shelf spares readily available for this cost effective hopper

• Fill volume from 5 to 200 Litres
• Tank and Chute in stainless steel outside brushed
• Belt FDA-convenient
• Adjustable raised face in stainless steel
• Curtain lock
• 3-phase motor

The BU-S hopper belts serve to store light, bulky components and, in interaction with a vibratory bowl feeder, they increase the autonomy of the feeding system.

The hopper belts of the BU-S type are based on the RNA conveyor belts of the series FP120 or FK120. The BU-S hoppers are available with a filling volume of 65 to 350 Litres. Depending on the space required, the user can choose the hopper belts in different sizes.

• Low fill height
• Easy access and gentle handling of components
• Simple control integration utilising RNA standard control boxes
• Low cost, short lead time
• Lightweight & mobile with a small footprint
• Low noise levels
• Off the shelf spares readily available for this cost effective hopper

The new STF series from RNA is a high quality standard and bespoke vertical conveyor, available in various sizes and belt widths.

• A hopper system eliminates jamming of the parts between the conveyor belt and cover or hopper wall.
• The adjustable baffle plate in the spout prevents parts from getting under the back belt cover.
• The open design of the lower deflection station prevents parts jamming.
• The new series is optimized with regards to the filling height, the variable discharge height and noise reducing measures.
